TOKii-HSF-03050

Automatic Press-Down Screw Feeder

Enquire Now
Categories: ,
Key Features

Product Highlights

The TOKii-HSF-03050 is an automatic press-down screw feeder designed for feeding M1.4–M5 screws with a maximum length of 20 mm. It uses a press-down feeding mechanism and discharges one screw per cycle. The unit operates at 220VAC / 50Hz with 0.4–0.6 MPa working air pressure and provides a feeding efficiency of approximately 0.7 seconds per screw.

  • Applicable Screw: M1.4–M5, maximum 20 mm length
  • Feeding Type: Automatic press-down type
  • Discharge Mode: One screw per cycle
  • Working Air Pressure: 0.4–0.6 MPa
  • Input: 220VAC / 50Hz
  • Feeding Efficiency: Approximately 0.7 seconds per screw
  • Feeder Capacity: Approximately 3,000 pieces of M3.0 screws
  • Screwdriver Maximum Torque: 20 kgf・cm
  • Rated Power: 80W
  • Dimensions: 330 × 210 × 270 mm (L × W × H)
  • Equipment Weight: Approximately 16 kg
  • Accessories: 2 screwdriver bits, 1 hanging spring, 1 power cord, and 2.5-meter air intake pipe
Attachments

Product Datasheet

Download
