Tokii

TOKii-ABSF

Automatic Rotary Screw Feeder

Enquire Now
Categories: ,
Key Features

Product Highlights

The TOKii-3000ABF is an automatic screw feeder designed for fast and efficient screw feeding in assembly operations. It uses a rotary feeding system and is dedicated to feeding one screw size per feeder, with applicable screw sizes from M1.0 to M5.0 and lengths up to 20 mm. The system includes a screwdriver and screw mount, with a discharge speed of 60–120 pieces per minute.

  • Applicable Screw Size: M1.0–M5.0, one screw size per feeder
  • Maximum Screw Length: 20 mm
  • Feeder Type: Rotary feeding
  • Discharge Speed: 60–120 pcs/min
  • Effective Silo Capacity: 450 ml
  • Input Voltage: AC 220V
  • Working Pressure: 0.4–0.6 MPa
  • Rated Power: 0.15 kW
  • Product Dimensions: 140 × 163 × 266.5 mm (L × W × H)
  • Weight: Approximately 15 kg
  • Tray Specifications: Φ130 mm
  • System Components: Screwdriver and screw mount included
