TOKii-ABF
TOKii-ABF
Back to products
Next product
TOKii-04SCDC
TOKii-04SCDC
Tokii

TOKii-04SCBS

Screw Counter for ASA BS Series Tools

Enquire Now
Categories: Screw Assembly Solutions, Screw Counter
Share
  • Key Features
  • Attachments
Key Features

Product Highlights

The TOKii-04SCBS is a programmable screw counter designed for use with ASA BS Series tools. It supports screw counting from 1–99 pieces and provides configurable inputs, outputs, counting direction, job settings, timing functions, and torque display for controlled fastening operations. The system can monitor screwdriver start and torque signals, help prevent mis-counting, and provide PASS/FAIL control for assembly processes. It also supports up to 16 different JOB IDs and Wi-Fi-based OTA firmware updates.

  • Application: Designed for ASA BS Series tools
  • Screw Count: 1–99 screws
  • Input Configuration: 3 configurable inputs for NPN/PNP sensors or N.O. switches
  • Output Configuration: 3 configurable outputs for PASS, FAIL, screw pulse and clamp functions
  • Runtime Protection: Programmable maximum runtime to stop the screwdriver during overrun or free-thread conditions
  • Timing Function: ALL, EACH and Partial Tightening configurations
  • Timing Tolerance: Adjustable tolerance percentage for screw fastening time
  • Torque Display: Torque display and tool validation system
Attachments

Product Datasheet

Download
