TOKii-04SCBS
TOKii-04SCBS
Back to products
Next product
TOKii-1050SC
TOKii-1050SC
Tokii

TOKii-04SCDC

Screw Counter for ASA-7500/9000 Series Tools

Enquire Now
Categories: ,
Key Features

Product Highlights

The TOKii-04SCDC is a programmable screw counter designed for use with ASA-7500/9000 Series tools. It supports screw counting from 1–99 pieces, configurable input and output functions, programmable job settings, timing control, and torque display and validation. The counter can monitor screwdriver start and torque signals and provides configurable PASS/FAIL and screw pulse outputs for controlled fastening operations.

  • Application: Designed for ASA-7500/9000 Series tools
  • Screw Count: 1–99 screws with selectable UP/DOWN counting
  • Input Configuration: 3 inputs configurable for NPN/PNP sensors or N.O. switches
  • Output Configuration: 3 outputs configurable for PASS, FAIL, screw pulse and clamp functions
  • Runtime Protection: Programmable maximum runtime to stop the screwdriver in case of overrun or free-thread conditions
  • Timing Function: ALL and EACH timing configurations for screw fastening; Partial Tightening does not work with DC Series tools
  • Timing Tolerance: Adjustable percentage tolerance for fastening time
  • Torque Display: Torque display and tool validation function in kgf·cm
  • Torque Training: 15 torque values are trained using a torque meter
Attachments

Product Datasheet

Download
