BDT3TS
Tokii

TOKii-ABSF

Hand-Held Automatic Screw Feeder

Enquire Now
Categories: ,
Key Features

Product Highlights

The TOKii-010618ABF is a hand-held automatic screw feeder with a blowing-type feeding system, designed for M1.0 to M6.0 standard screws and screws with gaskets. It supports screw lengths below 18 mm and provides a conveying distance of 1–4 meters. The unit uses spiral feeding with an electromagnetic vibration mode and delivers an output speed of 60–120 pieces per minute.

  • Applicable Screw Size: M1.0–M6.0
  • Maximum Screw Length: Less than 18 mm
  • Feeder Type: Hand-held automatic screw machine
  • Feeding Type: Blowing type
  • Feeding Method: Spiral feeding
  • Vibration Mode: Electromagnet
  • Output Speed: 60–120 pcs/min
  • Conveying Distance: 1–4 meters
  • Working Voltage: AC 220V / 50Hz
  • Working Pressure: 3–6 kgf/cm²
  • Machine Power: 30W
  • Machine Noise: Less than 65 dB
  • Screw Pocket Capacity: Approximately 10,000 standard screws
  • Operating Temperature: -20°C to 40°C
  • Weight: Approximately 12 kg
  • Product Size: 37 × 22 × 28 cm
Attachments

Product Datasheet

Download
