Product Highlights
The TOKii-HSF-03020 is an automatic press-down screw feeder designed for feeding M2–M3 screws with a maximum length of 20 mm. It uses a press-down feeding mechanism without cylinder expansion or contraction and discharges one screw per cycle. The unit operates at 220VAC / 50Hz with 0.4–0.6 MPa working air pressure and provides a feeding efficiency of approximately 0.7 seconds per screw.
- Applicable Screw: M2–M3, maximum 20 mm length
- Feeding Type: Automatic press-down type
- Discharge Mode: One screw per cycle
- Working Air Pressure: 0.4–0.6 MPa
- Input: 220VAC / 50Hz
- Feeding Efficiency: Approximately 0.7 seconds per screw
- Feeder Capacity: Approximately 3,000 pieces of M3.0 screws
- Screwdriver Maximum Torque: 20 kgf・cm
- Rated Power: 80W
- Dimensions: 330 × 210 × 270 mm (L × W × H)
- Equipment Weight: Approximately 16 kg
- Accessories: 2 screwdriver bits, 1 hanging spring, 1 power cord, and 2.5-meter air intake pipe
