Product Highlights
The TOKii-DTM100 is a digital torque meter designed for accurate torque measurement and test data management. It provides a 0.5-100 kgf·cm measuring range with peak value holding and supports torque measurement in kgf·cm, lbf-in and N·m. The meter can automatically calculate and store average test data, store and print up to 10 test results, and print test curves. It also features automatic alarm settings, adjustable automatic shutdown and automatic charge control.
- Measuring Range: 0.5–100 kgf・cm
- Torque Units: kgf·cm, lbf-in and N·m
- Accuracy: Within ±0.5%
- Peak Hold: Peak value holding function
- Data Storage: Stores and prints up to 10 test data
- Average Calculation: Automatically calculates and stores average test data
- Test Curve: Test curves can be printed
- Alarm: Automatic alarm settings
- Sampling Rate: 600 Hz
- Battery: Lithium battery
- Power Saving: Adjustable automatic shutdown from 1 to 60 minutes
- Operation: Light-touch keys and automatic charge control
