Product Highlights
The TOKii-619C is an automatic screw feeder designed for robot-assisted screw feeding applications. It is dedicated to one screw size from M1.0 to M5.0, with a maximum screw length of 16 mm and a discharge speed of 60–90 pieces per minute. The feeder provides signal output for automatic robot integration and supports repeated positioning accuracy of ±0.025. Its compact design includes jam reversal and fault alarm functions for controlled screw feeding.
- Applicable Screw: M1.0–M5.0, dedicated to one screw size
- Maximum Screw Length: 16 mm
- Discharge Speed: 60–90 pcs/min
- Robot Integration: Signal output for automatic robot applications
- Positioning Accuracy: Repeated positioning accuracy of ±0.025
- Feeding Function: One-by-one screw transfer from guide rail outlet to material port
- Jam Protection: Jam reversal function
- Fault Protection: Fault alarm function
- Silo Capacity: 200 ml effective capacity
- Input Voltage: AC220V
- Power Supply: AC100–220V input / DC15V output
- Picking Point Height: 76 mm
- Dimensions: 202.5 × 126 × 149 mm
- Weight: Approximately 2.9 kg
- Certification: CE and RoHS certification
